RoboSense E1R - All-Solid-State Digital LiDAR for Robots | 120°×90° FOV | 75m Long-Range Detection | 260,000 Points/Sec | for Delivery, Cleaning, Humanoid Robots & Drones

Description:​​ Introducing the RoboSense E1R – a breakthrough in LiDAR technology designed specifically for next-generation robots. Combining solid-state architecture with advanced digital SPAD-SoC chip technology, the E1R delivers unmatched precision, efficiency, and robustness in a compact form factor. Engineered for diverse applications—including delivery robots, cleaning robots, humanoid robots, and drones—the E1R excels in dynamic environments. Its wide 120°×90° FOV and long-range detection (up to 75m) help robots perceive small static and dynamic obstacles like cones, pedestrians, and vehicles with clarity. Meanwhile, its high point cloud rate (260,000 pts/sec) supports real-time 5D SLAM and detailed 7D mapping in complex scenes such as warehouses, ports, and residential areas. The E1R is not only powerful but also built to last. It passed over 60 reliability tests, ensuring stable performance under extreme temperatures, strong vibrations, and challenging conditions like rain or dust. Its streamlined design, featuring a flat window and minimal thickness, enables elegant integration without compromising on aesthetics or functionality. Whether you’re developing autonomous commercial robots or innovative AI-driven machines, the E1R provides the sensing intelligence needed to navigate, decide, and perform with confidence. ​​Product Specifications:​​.. Field of View: 120° (H) × 90° (V). Detection Range: 75m (max), 30m (@10% reflectivity). Point Cloud Rate: 260,000 points/second. Line Resolution: 144 lines. Window Dimensions: 7mm (H) × 35mm (V) × 75mm (W). Operating Temperature: -40°C to +85°C. Protection Rating: IP67 / IP6K9K. Mount: 1/4" threaded interface. Applications:​​ Ideal for autonomous delivery robots, cleaning robots, humanoid robots, UAVs, and industrial automation systems. In The Box: Power Adapter × 1 AC Power Cable × 1 Power Junction Box × 1 RJ45 Ethernet Cable (dual-ended) × 1 M4 Mounting Screws × 6 3.5m Ethernet Power Cable Harness × 1 (for shorter-range applications)

• Revolutionary Solid-State Design​​: As the world’s first fully solid-state digital LiDAR dedicated to robots, E1R features no moving parts, ensuring exceptional durability and reliability even in harsh environments.
• Superior Perception​​: With a 120°×90° wide field of view and a max range of 75m (30m @10% reflectivity), it captures high-resolution 3D data, enabling precise obstacle detection and SLAM in both indoor and outdoor settings.
• ​​Ultra-High Point Cloud Density​​: Generates 260,000 points/second with 144-line structured scanning, delivering detailed environmental modeling for accurate navigation and decision-making.
• ​​Compact & Elegant Integration​​: Its slim profile (7mm window thickness) and flat window design allow flexible, seamless installation on various robot structures, along with a standard 1/4" threaded mount for easy debugging.
• ​​All-Weather Reliability​​: Built on automotive-grade E-platform standards, it operates from -40°C to +85°C, withstands 50G vibration shocks, and boasts IP67/IP6K9K ratings for dust/water resistance.
